Ponto Eletrônico Indutivo sem fio


Modelo                        Telsate WEIR – G

Maximo. volume            110 dB SPL

Faixa de Freqüência       200Hz ~ 7100Hz

Maxima. Distorção         < 6% ( 300Hz to 3KHz)

Corrente consumo         0,36 Ma (vol @ 80 dB SPL)

Tipo de Bateria              A10 (Zinc–Air 1,4 Vcc)

Peso:                           1,2 grams (com bateria)






Ponto Eletrônico Indutivo sem fio


Modelo                        Telsate  WEIR – S

Maximo. volume            110 dB SPL

Faixa de Freqüência       200Hz ~ 7100Hz

Maxima. Distorção         < 5% ( 300Hz to 3KHz)

Corrente consumo         0,36 Ma (vol @ 80 dB SPL)

Tipo de Bateria              312 (Zinc–Air 1,4 Vcc)

Peso                             2,1 grams (com batteria)

Volume e Tom               Ajustável






Ponto Eletrônico RF Receptor VHF


Modelo:                       Telsate WEIR - RF

Faixa de Freqüência       130~230MHz

Sensibilidade                 -100 dBm

Modulação                    6 KHz FM

Volume de Áudio           45 dB

Tipo de Bateria              312 1,4 Vcc

Corrente Stand By         2,5 mA

Volume e Tom               Ajustável






Ponto Eletrônico Indutivo sem fio


Modelo:                       Telsate WEIR–Retro

Max. volume:                110 dB SPL

Freqüência;:                 200Hz ~ 7100Hz

Max Distorção:              < 5%

Corrente consumo:        0,36 Ma

Tipo de Bateria:            312 1,4 Vcc)

Peso:                           1,5 gramas

Volume e Tom:             Ajustável


















Telsate Interphone


Radio Comunicação Digital Full Duplex (mãos livres) de dimensões 72X39X19 e peso 55 gramas quando utilizado em conjunto do Ponto Eletrônico WEIR-S  e o Transdutor Colar permite uma comunicação em Full Duplex discreta e Invisível ou opção de  Headset  p/equipes de Resgate a prova de água nível IP58








Microphone Body Pack Transmitter


Modelo                        Telsate  WMT-B

Faixa de Freqüência:      400~800Mhz

Oscilador:                     PLL/cristal

Canais:                        08

Tipo de Emissão:           FM

Potencia de RF ajustável: 10 ~100Mw

Alimentação Bateria:     2,4V Recarregável

Dimensões:                  21/60/85 mm

Peso:                           86gramas






Body Pack Receiver


Modelo                         Telsate  WMR-B

Faixa de Freqüência:      400~800Mhz

Oscilador:                     PLL/cristal

Canais:                        08

Tipo de Recepção:         FM

Potencia de Áudio ajustável: 10 ~100Mw

Alimentação Bateria:     2,4V Recarregável

Dimensões:                  21/60/85 mm

Peso:                           86gramas






WMRBS BASE STATION RECEIVER
Receiving Frequency: 400 to 500 Mhz
Oscillator: PLL Synthesizer
Channels: 8 pré-programmed
Type of Reception: FM
Image Rejection: >70dB
Reference Deviation: +/- 75 KHz
T.H.D.: < 1%
Pre/De - Emphasis: 50 us
Frequency Response: 100Hz to 15 KHz
Audio Output Level: 0 to 300mV/1Kohms
Output Connector: 1/4 Monophone Jack
Operating Voltage: 12 VDC
Dimensions W/H/D: 190 /36/100 m/m
Weight: 200g


WMTBS BASE STATION TRANSMITTER
Carrier Frequency: 400 to 500 Mhz
Oscillator: PLL Synthesizer
Channels: 8 pré-programmed
Type of Emission: FM
Antenna integral: W / Output cable
Input Connector: 1/4 Monophone Jack
Reference Deviation: +/-75Khz
Frequency Response: 100 Hz to 15 KHz
RF Output: 50 mW
spurious: < 60db
S/N Ratio: >110dB
Operating Voltage: 12 VDC
Dimensions W/H/D: 190 /36/100 m/m
Weight: 200g


WMT MICROPHONE BODY PACK TRANSMITTER
Carrier Frequency: 400 to 500 Mhz
Oscillator: PLL Synthesizer
Channels: 8 pré-programmed
Type of Emission: FM
Antenna integral: W / Output cable
Input Connector: 3,5 mm Jack
Reference Deviation: +/-75Khz
Frequency Response: 100 Hz to 15 KHz
RF Output: 50 mW
spurious: < 60db
S/N Ratio: >110dB
Operating Voltage: 3V (2AA size)
Dimensions W/H/D: 60/92/23 mm
Weight: 100g


WMR BODY PACK RECEIVER
Receiving Frequency: 400 to 500 Mhz
Oscillator: PLL Synthesizer
Channels: 8 pré-programmed
Type of Reception: FM
Image Rejection: >70dB
Reference Deviation: +/- 75 KHz
T.H.D.: < 1%
Pre Emphasis: 50 us
Frequency Response: 100Hz to 15 KHz
Audio Output: 0,2 W at 32 ohms
Output Connector: 3,5 mm Jack
Operating Voltage: 3V (2AA Type)
Dimensions W/H/D: 60/92/23 m/m
Weight: 100g


MINIATURE WIRELESS RECEIVER / PONTO ELETRÔNICO
Microcall is a miniature inductor receiver, long-range cuing system providing a performer with first quality auditory assistance. It is simple and easy to use the prompters wears the WMT wireless microphone transmitter. The performer wears the WMR companion receiver and neck-loop transdutor that transmits the audio to the Microcall inductor receiver comfortably concealed in the ear. Application: personal cuing, professional studio communication and security agent.


CONFERENCE SPEAKERPHONE
The fullduplex communication of Conference Speakerphone using the DSP technology offers a communicative quality other than half-duplex communication that interfering noise always exists, the advanced DSP algorithim has the features of echo cancellation and suppression of environmental noise it has Three built-in microphones offers a 360 degree of coverage and it has the option to use two extension microphones. The RCA audio jack supports a record, standard phone lines pabx system can be easily fitted with this system.


PERSONAL WIRELESS PA SYSTEM/ MEGAFONE SEM FIO
Receiving Frequency:160 to 250 Mhz
Oscillator: Quartz Controlled
Type of Reception: FM

Image Rejection: >70dB
Reference Deviation: +/- 15 KHz
T.H.D.: < 1%
Pre Emphasis: 50 us
Frequency Response: 100Hz to 15 KHz
Power Output: 20 W at 4 ohms
Speaker: Built in 5´´
Output Connector: 3,5 mm Jack
Input connector: Monophone Jack
Operating Voltage: 12V rechargeable battery
Dimensions W/H/D: 160/178/285 m/m
Weight: 2,95 Kgs


MICROPHONE BODY PACK TRANSMITTER
HANDHELD WIRELESS MICROPHONE

Carrier Frequency:160 to 250 Mhz
Oscillator: Quartz Controlled
Type of Emission: FM
Antenna Integral: Built in

Deviation: +/- 15 KHz
Frequency Response: 100Hz to 15 KHz
RF Output: 30mW
Spurious: <60dB
S/N Ratio: >110dB
Operating Voltage: 9 VDC
Dimensions W/H/D: 60/105/20 m/m
Weight: 100 g
